Cast Iron Comparator Stand

Model No. Reference Surface (mm) Measuring Height (mm) Throat Depth (mm) Post Diameter (mm) Gaging Bracket
L – 12 60 100 65 25 Plain
L – 13 60 Serrated 100 65 25 Fine Adj.
L – 14 100 x 125 Serrated 150 95 25 Plain
L – 15 100 x 125 Serrated 150 150 25 Double Shaft
L – 16 100 x 125 Serrated 150 95 25 Fine Adj.
L – 17 225 x 150 200 150 28 Plain
L – 18 225 x 150 200 125 28 Fine Adj.
L – 19 300 x 300 250 150 28 Plain
L – 20 300 x 300 250 220 28 Double Shaft
L- 21 300 x 300 250 125 28 Fine Adj.

Description

Cast iron comparator stands are made of closed grain graded casting and are hand scrapped to achieve accuracy of grade – 1.
Rigid and sturdy base. Serrated and Plain anvil face are hardened and ground finish. These have high wear resistance. Adjustable support arm of dial indicator.
